Product Description

Fine adjustment and fitting to the beam is extremely easy by
adjusting the round units.
Easily adjustable (round nuts) to fit a wide range of beam widths
Adjustable to fit a wide range of beam profiles.
Excellent rolling features due to machined steel wheels mounted
on prelubricated,encapsulated ball bearings.
Anti-tilt and anti-drop devices are standard request.
Both normal beam and long beam is available.

 TROLLEY HOIST PLAIN TROLLEY 01298 01299 01290-L 01291-L 01292-L 01293-L 01294-L 01295-L 01296-L 01297-L 01298-L 01299

ITEM NO(I-BEAM:NORMAL)

01290

01291

01292

01293

01294

01295

01296

01297

01298

01299

ITEM NO(I-BEAM:LONG)


01290-L

01291-L

01292-L

01293-L

01294-L

01295-L

01296-L

01297-L

01298-L

01299-L

Rated capacity

kg

0.5

1

1.5

2

3

5

7.5

10

15

20

Test load

KN

7.35

14.71

22.06

29.42

44.13

61.29

98.06

122.58

196.12

196.12

Min. radius of curve

M

0.85

1

1.1

1.1

1.3

1.4

2

2

3.5

3.5

Dimensions (mm)

a

263

303

310

317

333

322

372

378

449

449

b

296

405

412

419

435

457

474

480

551

551

B

258

292

319

358

434

448

628

636

757

757

C min

385

451

489

551

629

1165

916

965

1020

1020

H min

299

331

383

411

460.5

978.5

707

745

750

915

S

30

35

38

38

40

42

45

45

56

58

Z

7.5

10.05

4.5

12

14

15


F

1.5-3

2-3.5

I-Beamwidth range(mm) M

a

50-152

64-203

74-203

88-203

100-203

114-203

124-152

124-203

136-203

136-203

b

50-203

64-305

74-305

88-305

100-305

114-305

124-305

124-305

136-305

136-305
