GRADE S BOW SHACKLE WITH SAFETY PINS AS2741 20968 20969 20970 20971 20972 Admin Edit

20961 20962 20963 20964 20965 20966 20967 20968 20969 20970 20971 20972


Product Description

Hot Dipped Galvanized.
      Body Forged Carbon Steel, and Pin Forged Alloy Steel.
      Test load is 2.2 times Working Load Limit.
      Ultimate Load is 6 times Working Load Limit

ITEM NO

SIZE

D

d

B

H

SWL



mm

mm

mm

mm

t

20961

13

13

16

21

48

2.00

20962

16

16

19

27

61

3.20

20963

19

19

22

32

72

4.70

20964

22

22

25

37

84

6.50

20965

25

25

29

43

95

8.50

20966

29

29

32

46

108

9.50

20967

32

32

35

52

119

12.00

20968

35

35

38

57

133

13.50

20969

38

38

41

60

146

17.00

20970

44

44

51

73

178

25.00

20971

51

51

57

83

197

35.00

20972

63

63

70

105

267

55.00

Category: Shackle
