STRUCTURE CLAMP LC TYPE Admin Edit
Item No | 01731 | 01732 | 01733 | |
WLL | kg | 1000 | 2000 | 3000 |
Opening size | 1-13mm | 3-22mm | 12-35mm | |
L | mm | 173 | 233 | 261 |
t | mm | 14 | 18 | 23 |
T | mm | 32 | 42 | 52 |
H | mm | 104 | 130 | 177 |
h1 | mm | 23.5 | 36 | 42 |
h2 | mm | 39.5 | 50 | 67.5 |
B | mm | 105 | 137 | 173.5 |
b1 | mm | 66 | 87 | 107 |
b2 | mm | 44 | 58 | 68 |
D | mm | 72 | 96 | 80 |
d | mm | 46 | 61 | 35 |
